1)
Externally Control Operation of Motor Control System
In this mode, the external host such as a PC, micro-controller
or PLC sends a series of commands to the controller via the
RS-232 serial port. The controller processes and performs the
incoming commands and responds with proper messages.
2)
Operating the Motor Control System Using the
Supplied Control Panel
The supplied
user friendly Control Panel software allows the user
to set-up the module quickly. The operator is able
to move the mechanism to different positions by
pressing the corresponding buttons of the Control
Panel or by using the joystick and/or trackball.
1) Teach Mode
The motion profile may be recorded using the "Teach Mode"
capability of the software. This profile may be uploaded to the
controller to repeat the same exact Stepper Motor.
2)
Profile Entry Mode
The motion parameters are manually entered in the control panel by typing
the desired values in the corresponding fields, or may be read from a
text file.
